Model ID: 100-500-6

MTO 100-500-6 Single Column UTM

Architecture

NEWTON™ 32-BIT

An over-built, high-rigidity single-column benchtop frame engineered to minimize mechanical compliance. It delivers a 2.2 kN force capacity across a short 150 mm travel profile, maximizing frame spring rates and preserving parallel alignment under localized compression or insertion loads.

Frame Capacity2.2 kN

Frame StyleBenchtop

Frame TypeSingle Column

Newton TierStrength

High-Throughput Material Evaluation & Break Testing

The Newton Strength Platform is purpose-built for quality control laboratories, manufacturing environments, and high-volume testing facilities where speed, reliability, and precise peak-load verification are essential. Designed for efficient monotonic tensile, compression, and flexural testing, it provides operators with an intuitive and dependable interface for capturing yield points, break forces, and ultimate elongation data. Whether validating metals, rigid plastics, fasteners, or construction materials against international standards, Newton Strength delivers the structural stability and accurate data acquisition needed to maintain consistent product quality and keep production lines running smoothly.

Machine Details

Stiffness:

0.37 kN/mm

Daylight Standard:

785 mm

Daylight Extended:

1700 mm

Clearance:

76 mm

Travel:

150 mm

Optional Travel:

300 mm

Max Speed:

300 mm/min

Minimum Speed:

0.003 mm/min

Resolution:

0.001 μm

Value Position:

Electronic component validation

Compatible Applications

Applications & Expert Insights

Expert Nugget

Over-built construction minimizes load frame compliance during high-load insertion/extraction profiles.

Expert Commentary

Specifically configured to match high-stiffness requirements for electronic terminals and solder point shear trials.

Pro Tip

SOLDER SEAR PROFILE: For PCB components, use an adjustable base stage to line up crosshead displacement vectors parallel to the surface traces.

Machine Hardware

Machine Type:

Static

Test Type:

Compression, Tension

Drive Type:

Electromechanical

Applications:

Solder Joint Shear, Connector Insertion/Extraction, PCB Flexure, Micro-Switch Actuation Profiles

Load Cell:

500 lbf

Power:

120V Standard AC

Weight:

~36 kg

Footprint:

300 x 300 mm
